| Model | Studio Size | Rated Power (KW) | Rated Temperature(℃) | Loading Capacity(Ton) |
| RS-55-6 | Ф800*1650 | 55 | 600 | 1-1.5 |
| RS-75-6 | Ф1400*2000 | 75 | 600 | 1.5-2 |
| RS-90-6 | Ф1700*2000 | 90 | 600 | 2-3 |
Application: The industrial aluminum furnace is suitable for heating treatment such as ordinary annealing before pulling up, such as aluminum wire, copper wire, and round wire.
Introduction of Industrial Aluminum Furnace
1. The industrial aluminum furnace is composed of an electric furnace body, a furnace lining, a furnace cover, a heating element, a temperature control cabinet and the like.
2. The skeleton of the furnace body is welded by a combination of steel and steel plates.
3. The lining of the industrial aluminum furnace is made of high-temperature resistant aluminum silicate fiber cotton, which is made into a furnace-like module after being laid and stacked, and is fixed on the furnace shell by stainless steel round steel. The bottom of the furnace is made of perlite insulation bricks and standard refractory clay bricks, and the load-bearing parts are made of heavy high-alumina bricks.
4. The furnace cover is welded round by profile steel, and all of them are made of refractory aluminum silicate fiber reinforced silk carpet extrusion assembly, which is useful for ensuring heat insulation and sealing.
Features:
Easy installation and short construction time
Low heat storage, low heat loss, good energy saving effect and long service life
The body of industrial aluminum furnace has good sealing performance and convenient maintenance
SHIPMENT
